Key Components

Power Source
2 AC motors with 400kW Peak (536 hp) & 334 kW (448 hp) continuous power
Batteries
4 NMC lithium-ion batteries (Lithium Nickel Manganese Cobalt Oxide), 600V, fast charge capability
Transmission
2-speed Mack Powershift 4,051 lb.-ft. peak output torque
Charging System
Up to 150kW charge power with a max current of 200A, 550-750 volts, compliant with SAE J1772
Auxiliary Power
Circuits: 12, 24 and 600V, 260 Amp. Powering PTO, steering assist, pneumatic, and climate systems
Brakes
Two-stage regenerative

Specifications

Weight Rating (GVWR)
66,000 lbs.
Axles
Mack FXL20 20,000-lb. front axle
Mack S462R 52,000-lb. rear axles
Mack mRIDETM 46,000-lb. suspension
Service and Training
Supported through Mack dealership network
Payload
Up to 25,500 lbs.
Comfort
Extended cab for more room; a tilt and telescopic steering column; new seat positions; suspended pedals; adjustable
knee bolsters and armrests; integrated air conditioner
Operating Range
Up to 100 on-the-job miles
Charging Time and Rate
About 120 minutes @ 150kW
